Clarke CXR100DR 37.1cfm 270Litre 10HP Industrial Screw Compressor With Dryer (400V)

Back to product list
Product Code 000110053
Manufacturer sku 2456320
£4,890.00INC
VAT
Qty

Add to basket


Finance available

From £ per month
Pay Monthly

Built to combine total reliability with high performance and minimum energy consumption, this superb range of screw compressors offers state of the art technology at exceptionally keen pricing.Features:Easy...Read more

  • 400V - 3 Phase Motor
  • Power: 10HP/7.5kW
  • 270 Litre Capacity
  • 10bar Maximum Pressure - 37.1cfm Air Displacement
  • Pre-Mounted to air receiver and fitted with a dryer
  • Dimensions (LxWxH): 1200x600x1500mm
  • Weight: 240kg
View technical specification

Products you may also consider

Customer Reviews ()

Sign in or register to leave a review
Showing of reviews

Full product description

Built to combine total reliability with high performance and minimum energy consumption, this superb range of screw compressors offers state of the art technology at exceptionally keen pricing.

Features:

Easy Installation • Will fit easily through a 900mm doorway. • Compact design saves on space required. • Construction allows positioning with a pallet truck • Simply connect to air system and electrical supply (all units are fully tested before dispatch) • No need for floor fixing due to vibration free operation

Comprehensive Digital Control Panel Constantly monitors: • Air Pressure • Oil temperature • Motor temperature • Condition of all filters • Hours run • Indicates when maintenance is due • Indicates excessive temperature prior to shut-down • Controls on demand mode of operation, continuous or automatic.

Easy Maintenance • Removable side panels for full access • Simple screw-on oil cartridge and oil separator filters

Low Noise Level: Operates at 67 Db (A) removing the need for a separate enclosure, which maximises flexibility for choice of location.

Superb Build Quality: Construction and performance satisfy relevant European standards

Integral Refrigerant Dryer: Pre connected to the unit for easy installation and operation. Built to provide cool, dry air, dryer performance is enhanced by receiving cooler air from the air receiver.

Technical Features:

1. Large oil separator tank ensures minimal oil carry over (typically as low as 3mg/m3)

2. Minimum pressure valve ensures correct oil pressure & lubrication

3. Thermostatic valve controls oil temperature and prevents condensation developing inside the oil separator tank

4. Suction valve adjusts compressor output

5. Over sized suction filter ensures maximum air intake filtration, thereby reducing maintenance and extending oil and compressor life

Technical specification

Motor (HP) 10
Volts 400
Receiver capacity 270 L
Free air 37.1 cfm
Max Working Pressure 145/10 psi/bar
Maximum Electrical Power 7.5 kW
Please note that details and specifications contained herein, are correct at the time of publishing. We reserve the right to change specifications at any time without prior notice.
